- Alternate parts in the family(Compare): ICEpower200AS1
- Moisture sensitivity level: 1
- RoHS 3(EU 2015/863)
-
Pack sizes & weights (for bulk orders) EACH 1 0.510kg BOX 30 12.400kg
Active
ICEpower200AS1 1 Channel 200W Amplifier with Power Supply
Sku:
ICEPOWER200AS1
Features
- Fully integrated amplifier
- Standby mode
- 1 x 200W / 4Ω @ 1% THD+N, 1kHz
- 0.003 % THD+N @ 1kHz, 10W / 4Ω
- 30 kHz audio bandwidth
- < 92 uV A-weighted output noise
- Minimum load impedance at 2.7Ω
The ICEpower 200AS1 features an extremely capable fly back power supply with a continuous power capability of 160W and a short-term power of 300W, combined with a 200W class D amplifier.
The 200AS1 is designed for use in guitar amplifiers, bass amplifiers, subwoofers and active speakers without the need for forced cooling. The 200AS1 is pin compatible with the 100AS1 and 100AS2 and shares the same mechanical dimensions and mounting holes.
Number of Channels | 1 |
---|---|
Note | 0.003 % THD+N @ 1 kHz, 10 W / 4Ω |
Input | Analogue |
Supply Voltage (max) | 264V |
Supply Voltage (min) | 85V |
Efficiency | 78% |
THD plus Noise | 0.006% |
Note 2 | @1W rms |
Stand-by Control | Yes |
Mute Control | Yes |
