Active
LD1117AG50TN3AR LDO Voltage Regulator
Features
Low dropout voltage (1V Typ.) Output current up to 1A Internal current and thermal limit. Supply voltage rejection: 75dB (Typ.)
The UTC LD1117A is a low dropout, 3-terminal, positivevoltage regulator designed to provide output current up to1A.
Technical Specification
Voltage
-
Family Voltage Range
-
Supply Voltage (max)
15V
Output Current
1,000mA
Drop-out Voltage
1.15V
Voltage Reference Tolerance
2%
Ripple Rejection Ratio
75dB
Output Adjustable
No
Noise Bypass Terminal
No
Output Noise
0.3mV
Quiescent Current
2mA
Output Capacitor
-
