| Pack sizes & weights (for bulk orders) | ||
|---|---|---|
| TRAY | 250 | 0.530kg |
Sku:
SAM5504B
The SAM5504 is the lowest costed member of Dream's SAM5000 family, and features four 24-bit DSPs in a compact 64 pin LQFP package.
The DSP is ideally suited to a range of professional but cost sensitive audio processing applications such as digital speaker crossovers, small mixers, effects processing and musical instruments. It comes with USB 2 which can stream multiple audio channels.
The SAM5504 offers a large variety of parallel or low pin count memory interfaces, and like all SAM5000 Integrated Circuits it is built around Dream's optimized 16-bit CPU and a configurable array of hardware accelerated 24-bit DSP cores. With a sophisticated sample buffering system, multi-channel audio DMA and support for a large variety of memory types, the SAM5000 ICs deliver high performance sound synthesis, audio processing and effects generation.
The SAM5504's memory can be configured to provide the interfaces required for a wide range of audio applications, including: digital keyboards and pianos, effect devices, speaker processing and USB audio interfaces.
| Supply Voltage (max) | 3.6V |
|---|---|
| Number of Effects | - |
| Applications | Digital effects, Speaker crossover, USB audio interface |
| Number of Inputs | 14 |
| Number of Outputs | 14 |
